Lotion Boxes.
Final price depends on size, material, finish and quantity. Your packaging manager confirms it before production.
Your custom box, quoted.
The full specification book.
Six chapters. Six colours. Click a tab to turn the page.
Lotion Boxes
Close to 300 grams of emulsion, which is why the base is an auto-bottom rather than a tuck.
A tucked bottom under this weight eventually fails, usually in a warehouse stack rather than on a shelf. A crash-lock base spreads the load across the whole panel instead of one flap.

Every detail. Intentional.
Auto-bottom under a full bottle
Load across the panel, not one tucked flap.
HDPE slides
Waxy bottles need about 1.5mm total clearance.
60+ square inches of panel
So the ingredient list sits at a readable size.
Matte is the body-care default
Calm and consistent with the category.
Aqueous where claims apply
Recyclable coverage without a plastic laminate.
Kraft and PCW suit it
Cost and positioning point the same way here.

Built like architecture.
Every order of Lotion Boxes is an engineered build, measured, dieline-cut and hand-wrapped to spec. Below is the standard build sheet.
✦ Need a custom spec? Talk to our atelier. Every detail is negotiable.
Every surface, hand-selected.
What this product is built from, and the surfaces it takes. Below the build sheet sits the full swatch library. Every option applies across our range, and a physical swatch set is available on request.
Material
The board and paper your box is built from.
◷ ECO
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISHFinishes
How the outer surface looks, feels, and catches light.
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISHAdd-ons
Closures, linings, and hardware that complete the build.
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH
◷ FINISH✦ Mix and match across all three and we'll build your exact combination.
The full kit of capabilities.
Sizing & dieline.
We cut Lotion Boxes to a dieline built around your product instead of pulling a stock size off the shelf. Send us the length, width and height of the item (or the item itself) and we return a measured dieline, free, before you commit to anything.
Length, width and height of the item itself, at its widest points. Measure the product, not the box you happen to use today.
Allow 2–4 mm on each axis for a snug fit, and more if you are adding foam, a pillow insert or tissue.
We quote as Length × Width × Height. Tell us whether you are working in millimetres or inches and we match it.
✦ Not sure of your size? Send us the product and we measure it and build the dieline.
Pricing & minimums.
We price Lotion Boxes per specification rather than from a fixed list, because the same build in two different finishes can land at very different numbers. Below is what actually moves the price, so you can shape the spec before you request a quote.
The single biggest lever. Unit cost falls sharply as volume rises, because setup and tooling spread across more pieces.
Board weight and stock choice change both the raw material cost and the shipping weight of the finished run.
Foil, spot UV, embossing and soft-touch each add a pass on press. One or two lift the box; five compound the cost.
Full-bleed print inside and out costs more than a one-sided design on natural stock.
Foam, moulded pulp, velvet pillows, magnets and ribbon are priced per piece on top of the box itself.
Standard production is the base rate. Rush moves you up the production queue and carries a surcharge.
✦ Quotes returned within 24 hours.
Questions, answered.
Everything you need to know about Lotion Boxes.
Because a full 250ml bottle weighs close to 300 grams, and a tucked bottom under that load eventually lets go. It usually fails in a warehouse stack rather than on a shelf. A crash-lock base spreads the weight across the whole panel instead of one flap, and it locks as the carton is squared up on the packing line.
We specify the carton to stack six high in distribution.
About 1.5mm in total, because a waxy HDPE bottle slides if the carton is loose. Too much room and the bottle rattles on the inside of the carton, and too little slows the packing line. Height is the bottle plus the cap plus a few millimetres, measured with a pump head in its shipping position.
Send a filled bottle and we'll cut a blank to check the fit.
20pt SBS for heavier fills, or 18pt kraft where the range is natural and the bottle is lighter. The extra caliper on SBS keeps a full bottle from bowing the side panel. Kraft is common in body care for cost and for a plain, unbleached look. FBB trims board cost on a carton this size without losing stiffness.
Large multipacks move to E-flute corrugated, since a folding carton alone will not survive distribution at that weight.
Matte lamination is the body-care default, and aqueous coating is the choice where a recyclability claim applies. Soft-touch works on a carton this size because there is a lot of surface to feel, and it suggests the texture of the product inside. A deboss reads as restraint, which suits the category better than foil. Spot gloss over a botanical illustration is the usual accent.
High gloss is for mass fixtures where visual impact matters more than hand feel.
About 2.4 by 2.4 by 6.5 inches inside for 250ml with a pump or disc cap, and 2.0 by 2.0 by 5.5 inches for 150ml. A carton at 250ml gives more than 60 square inches of panel, so the ingredient list sits at a comfortable size. Front panel takes the brand and the claim, back takes the list and directions, sides take range navigation.
Every bottle mould is different, so the carton is cut from yours.
500 per size and print version. A 150ml and a 250ml carton are separate dielines and each needs its own 500, even with identical artwork. The upper limit is 100,000 per order.
Kraft and PCW recycled board are both available at the minimum quantity.
7 to 10 business days once the proof is approved, with a rush option at 5 to 7 business days. An auto-bottom carton is glued as well as cut, and that step is already inside the window. Samples take 5 to 7 business days and a glued sample is the way to confirm the crash-lock base holds a full bottle.
The sample fee is offset against the bulk order, and delivery is anywhere in the USA.
Yes, and body care is the easiest cosmetic category to keep single-material. Colour accuracy matters less here, so PCW recycled board works without the swatch problems a colour range has. Aqueous coating instead of a film lamination keeps the carton repulpable, and water-based inks are standard.
Kraft board with one ink and no coating is the plainest recyclable spec and reads as honest on a natural range.
